Template Object |
Super.Contactor.Order.Description |
Energize contactor |
Super.Contactor.DisableOffControl |
1 |
Super.Contactor.Feedback.Description |
Contactor is energized |
Super.Contactor.FbTimeLimit |
1.000000e+00 |
Super.Contactor.Alarm.DetectOn |
1 |
Super.Contactor.Alarm.DetectText |
Contactor feedback lost |
Super.Contactor.Alarm.EventType |
64 |
Super.Contactor.Alarm.EventPriority |
67 |
Super.Contactor.Alarm.EventFlags |
7 |
Super.Contactor.Alarm.MoreText |
|
Super.Contactor.Alarm.Attribute |
BaseComponent:Class-BasePumpAggr-Template.Super.Contactor |
Super.Contactor.Alarm.CtrlPosition |
1 |
Super.Contactor.Alarm.LockAttribute |
1 |
Super.CircuitBreaker.NotTripped.Description |
CircuitBreaker is tripped |
Super.CircuitBreaker.Alarm.DetectOn |
1 |
Super.CircuitBreaker.Alarm.DetectText |
Circuit breaker tripped |
Super.CircuitBreaker.Alarm.EventType |
64 |
Super.CircuitBreaker.Alarm.EventPriority |
67 |
Super.CircuitBreaker.Alarm.EventFlags |
7 |
Super.CircuitBreaker.Alarm.MoreText |
|
Super.CircuitBreaker.Alarm.Attribute |
BaseComponent:Class-BasePumpAggr-Template.Super.CircuitBreaker |
Super.CircuitBreaker.Alarm.CtrlPosition |
1 |
Super.CircuitBreaker.Alarm.LockAttribute |
1 |
Super.SafetySwitch.Alarm.DetectOn |
1 |
Super.SafetySwitch.Alarm.DetectText |
Safety switch is not on |
Super.SafetySwitch.Alarm.EventType |
64 |
Super.SafetySwitch.Alarm.EventPriority |
67 |
Super.SafetySwitch.Alarm.EventFlags |
7 |
Super.SafetySwitch.Alarm.MoreText |
|
Super.SafetySwitch.Alarm.Attribute |
BaseComponent:Class-BasePumpAggr-Template.Super.SafetySwitch |
Super.SafetySwitch.Alarm.CtrlPosition |
1 |
Super.SafetySwitch.Alarm.LockAttribute |
1 |
Super.OverloadRelay.Alarm.DetectOn |
1 |
Super.OverloadRelay.Alarm.DetectText |
Overload relay tripped |
Super.OverloadRelay.Alarm.EventType |
64 |
Super.OverloadRelay.Alarm.EventPriority |
67 |
Super.OverloadRelay.Alarm.EventFlags |
7 |
Super.OverloadRelay.Alarm.MoreText |
|
Super.OverloadRelay.Alarm.Attribute |
BaseComponent:Class-BasePumpAggr-Template.Super.OverloadRelay |
Super.OverloadRelay.Alarm.CtrlPosition |
1 |
Super.OverloadRelay.Alarm.LockAttribute |
1 |
Super.Mode.AlarmNotReadyM.DetectOn |
1 |
Super.Mode.AlarmNotReadyM.DetectText |
Check interlocks. Manual start is not allowed, not ready |
Super.Mode.AlarmNotReadyM.EventType |
64 |
Super.Mode.AlarmNotReadyM.EventPriority |
66 |
Super.Mode.AlarmNotReadyM.EventFlags |
7 |
Super.Mode.AlarmNotReadyM.MoreText |
|
Super.Mode.AlarmNotReadyM.Attribute |
BaseComponent:Class-BasePumpAggr-Template |
Super.Mode.AlarmNotReadyM.CtrlPosition |
1 |
Super.Mode.AlarmNotReadyM.LockAttribute |
1 |
Super.Mode.AlarmNotReadyA.DetectOn |
1 |
Super.Mode.AlarmNotReadyA.DetectText |
Check interlocks. Automode is not allowed, not ready |
Super.Mode.AlarmNotReadyA.EventType |
64 |
Super.Mode.AlarmNotReadyA.EventPriority |
66 |
Super.Mode.AlarmNotReadyA.EventFlags |
7 |
Super.Mode.AlarmNotReadyA.MoreText |
|
Super.Mode.AlarmNotReadyA.Attribute |
BaseComponent:Class-BasePumpAggr-Template |
Super.Mode.AlarmNotReadyA.CtrlPosition |
1 |
Super.Mode.AlarmNotReadyA.LockAttribute |
1 |
Super.Mode.Alarm1LocalMod.DetectOn |
1 |
Super.Mode.Alarm1LocalMod.DetectText |
Local mode is activated, remote control is not allowed |
Super.Mode.Alarm1LocalMod.EventType |
64 |
Super.Mode.Alarm1LocalMod.EventPriority |
66 |
Super.Mode.Alarm1LocalMod.EventFlags |
7 |
Super.Mode.Alarm1LocalMod.MoreText |
|
Super.Mode.Alarm1LocalMod.Attribute |
BaseComponent:Class-BasePumpAggr-Template |
Super.Mode.Alarm1LocalMod.CtrlPosition |
1 |
Super.Mode.Alarm1LocalMod.LockAttribute |
1 |
Super.Mode.Alarm2LocalMod.DetectOn |
1 |
Super.Mode.Alarm2LocalMod.DetectText |
Local mode is activated |
Super.Mode.Alarm2LocalMod.EventType |
64 |
Super.Mode.Alarm2LocalMod.EventPriority |
66 |
Super.Mode.Alarm2LocalMod.EventFlags |
7 |
Super.Mode.Alarm2LocalMod.MoreText |
|
Super.Mode.Alarm2LocalMod.Attribute |
BaseComponent:Class-BasePumpAggr-Template |
Super.Mode.Alarm2LocalMod.CtrlPosition |
1 |
Super.Mode.Alarm2LocalMod.LockAttribute |
1 |
Super.Mode.AlarmNotManOrd.DetectOn |
1 |
Super.Mode.AlarmNotManOrd.DetectText |
Automode active. Manual start/stop order is not allowed |
Super.Mode.AlarmNotManOrd.EventType |
64 |
Super.Mode.AlarmNotManOrd.EventPriority |
66 |
Super.Mode.AlarmNotManOrd.EventFlags |
7 |
Super.Mode.AlarmNotManOrd.MoreText |
|
Super.Mode.AlarmNotManOrd.Attribute |
BaseComponent:Class-BasePumpAggr-Template |
Super.Mode.AlarmNotManOrd.CtrlPosition |
1 |
Super.Mode.AlarmNotManOrd.LockAttribute |
1 |
Super.Motor.GraphConfiguration |
2 |
Super.Motor.DisableTempSwitch |
1 |
Super.Motor.TempSwitch.Super.DisableSwitch |
1 |
Super.Motor.TempSwitch.Super.Alarm.DetectOn |
1 |
Super.Motor.TempSwitch.Super.Alarm.DetectText |
High motor temperature |
Super.Motor.TempSwitch.Super.Alarm.EventType |
64 |
Super.Motor.TempSwitch.Super.Alarm.EventPriority |
67 |
Super.Motor.TempSwitch.Super.Alarm.EventFlags |
7 |
Super.Motor.TempSwitch.Super.Alarm.MoreText |
|
Super.Motor.TempSwitch.Super.Alarm.Attribute |
BaseComponent:Class-BasePumpAggr-Template.Super.Motor.TempSwitch |
Super.Motor.TempSwitch.Super.Alarm.CtrlPosition |
1 |
Super.Motor.TempSwitch.Super.Alarm.LockAttribute |
1 |
Super.Motor.DisableTempSensor |
1 |
Super.Motor.TempSensor.Super.DisableValue |
1 |
Super.Motor.TempSensor.Super.Value.Unit |
C |
Super.Motor.TempSensor.Super.Value.PresMaxLimit |
1.500000e+02 |
Super.Motor.TempSensor.Super.LimitHH.Alarm.MoreText |
|
Super.Motor.TempSensor.Super.LimitHH.Alarm.CtrlPosition |
1 |
Super.Motor.TempSensor.Super.LimitHH.Limit |
1.300000e+02 |
Super.Motor.TempSensor.Super.LimitHH.Hysteres |
3.000000e+00 |
Super.Motor.TempSensor.Super.LimitHH.TimeDelay |
1.000000e+00 |
Super.Motor.TempSensor.Super.LimitHH.Used |
1 |
Super.Motor.TempSensor.Super.LimitH.Alarm.MoreText |
|
Super.Motor.TempSensor.Super.LimitH.Alarm.CtrlPosition |
1 |
Super.Motor.TempSensor.Super.LimitH.Limit |
1.150000e+02 |
Super.Motor.TempSensor.Super.LimitH.Hysteres |
3.000000e+00 |
Super.Motor.TempSensor.Super.LimitH.TimeDelay |
1.000000e+00 |
Super.Motor.TempSensor.Super.LimitH.Used |
1 |
Super.Motor.TempSensor.Super.LimitL.Alarm.MoreText |
|
Super.Motor.TempSensor.Super.LimitL.Alarm.CtrlPosition |
1 |
Super.Motor.TempSensor.Super.LimitLL.Alarm.MoreText |
|
Super.Motor.TempSensor.Super.LimitLL.Alarm.CtrlPosition |
1 |
Super.Motor.TempSensor.Super.Trend.Multiple |
1 |
Super.Motor.TempSensor.Super.Trend.DataName |
BaseComponent:Class-BasePumpAggr-Template.Super.Motor.TempSensor.Super.Value.Ac |
Super.Motor.TempSensor.Super.Trend.StorageTime |
239 |
Super.Motor.TempSensor.Super.Trend.BufferStatus[0] |
1 |
Super.Motor.TempSensor.Super.Trend.BufferStatus[1] |
1 |
Super.Motor.TempSensor.Super.Trend.NoOfBuffers |
2 |
Super.Motor.TempSensor.Super.Trend.NoOfBufElement |
239 |
Super.Motor.TempSensor.Super.DefTrend |
BaseComponent:Class-BasePumpAggr-Template.Super.Motor.TempSensor.Super.Trend |
